Xinyuan XYB70SWT China Wheel Excavator Direct Sales Top 10 Excavator Manufacturers
Xinyuan XYB70SWT China Wheel Excavator Direct Sales Top 10 Excavator Manufacturers
Product Description
Basic Info.
| Model No. | XYB70SWT | Drive Type | Internal Combustion Drive |
| Bucket Capacity | 0.25-0.4m³ | Size | Medium-Sized |
| Certification | ISO9001:2000,ISo14001 | Condition | New |
| Machine Weight | 6645kg | Engine | YUCHAI |
| Powerlspeed | 48KW/2200rpm | Max Dlgglng Force | 35kn |
| Max travel Speed | 30km/h | transport Package | Nude Packing |
| Specification | 5835mm*2010mm*2800mm | trademark | Xinyuan |
| origin | China | Production Capacity | 10000 Pieces/Year |
Product Description
B70S product positioning: Economic Hydraulic Transmission wheel excavator. It is a cost-effective product with excellent performance, precise control, flexible mobility, reliable quality, comfortable experience, beautiful shape, convenient and practical features.
Machine weight is 6645KG, the overall length of the machine is only 5835mm, small turning radius. The body height is only 2800mm, which can pass through the lower height limit area. The compact size of the body, more flexible, can adapt to more operating environments.
Powerful Engine
The B70S system is equipped with Yuchai 4F30 series diesel engine, which meets the latest emission standards for off-road machinery, with high power and more powerful.
Advanced Fuel System
Adopt electric control high-pressure common rail fuel system, with even atomization, full combustion and low fuel consumption.
High Stability of Rotational Speed Control
Sudden load speed fluctuation less than 20r/min, high stability, fast response, high efficiency
New load-sensitive Hydraulic System
It can precisely control and provide the required hydraulic power according to the vehicle load, and the power loss is greatly reduced.
Efficient Heat Dissipation System
Body design separating line to isolate the high temperature area of the machine, so that the power heat does not affect the comfort and the temperature of the fuel tank components. Good gas cooling, low noise and better driving comfort.
Minimum Front Turning Radius
The B70S has an unparalleled advantage in loading operations because it takes up little space during operation but has a large overall operating range.
Large Capacity Fuel Tank
With a large capacity of 140L, the B70S can have a longer range with lower fuel consumption.
Large Wheelbase
It can provide strong support for the collection. Stability is good no matter when driving at high speed or steering.
Comfortable Driving Space
B70S has a spacious interior with large space for effective driver movement. Comprehensive large-size glass design with wide visibility and small blind spots. The front-mounted intelligent instrument panel has a rich display of operational information. The ergonomic layout of the operating device provides long hours of operation without fatigue. Equipped with heating and cooling air conditioner, creating a more comfortable operating environment. There are electronic throttle knob, cigarette lighter, storage compartment, storage net pocket and other practical configurations, which are in line with the safety standards of hydraulic excavator operating room, equipped with fire extinguishers, escape hammer etc.
Safety
The side of the cab is equipped with large size glass, so the driver has a better side view. The whole vehicle is upgraded with light alarm system for safe driving.
Environmental Friendly
Keep exhaust emission in line with our country's Emission Standards, the engine is environmentally friendly.
| SPECIFICATIONS | ||
| RANGE OF OPERATION | Max Digging Reach | 6535mm |
| Max Digging Depth | 3530mm | |
| Max Digging Height | 6715mm | |
| Max Dumping Height | 4905mm | |
| Min Front Radius | 2275mm | |
| Min Tail Radius | 1665mm | |
| DIMENSIONS | Overall Length | 5835mm |
| Overall Width | 2010mm | |
| Overall Height | 2800mm | |
| Wheel Base | 2410mm | |
| Tyre Type | 825-16 | |
| Width of Grouding | 430mm | |
| track | 1520mm | |
| Min Ground Clearance | 245mm | |
| Width of Bulldozing | 1910mm | |
| Rising distance of Bulldozing | 390mm | |
| Height of Bulldozing | 45mm | |
| Width of Bucket | 700mm | |
| TECHNICAL PARAMETERS | Model | XYB70SWT |
| Engine | YUCHAI 4F30 | |
| Rated Power | 48KW | |
| Rated Speed | 2200rpm | |
| Machine Weight | 6645kg | |
| Volume of Bucket | 0.25-0.4m³ | |
| Set Pressure of Main Overflow Valve | 24Mpa | |
| Max Digging Force | 35kn | |
| Gradeability | 35° | |
| Max traction Force | 32kn | |
| Max travel Speed | 30km/h | |
| Swing Speed of Platform | 10.5rpm | |
| Fuel Tank Capacity | 140L | |
| Hydraulic Tank Capacity | 120L | |
Fujian Xinyuan Heavy Industries Co.,Ltd. was established in 1990, is a professional wheel excavator manufacturer in China, specializing in designing and manufacturing wheel excavators for more than 30 years.
Our company is located in Hardware & Electrical Industrial Park, Luojiang Economic Development Zone Quanzhou China with registered capital RMB50 million, covers an area of 60,000 square meters. We now have more than 300 employees, R&D team is more than 50 persons. Our products are well sold all over China and exported to many countries and regions of the world, annual sales is around 1 billion.
We have our own trademark Xinyuan, our main products are hydraulic wheel excavators, range from 5-15 tons with standard setting, and relevant wheel excavator parts and accessories. Our products comply with Chinese and International quality standards and are highly welcomed in both domestic and overseas countries. With superior quality, outstanding performance and excellent services, xinyuan wheel excavators have built a superior good reputation in the market.
If you are interested in any of our products please feel free to discuss with us. We sincerely hope to establish successful long term mutually trading relationship with you in the near future. If you are looking for wheel excavators, Xinyuan Heavy Industries is your best choice!
FAQ
1. What are your main products?
A: Wheel excavators. We specialize in designing and manufacturing wheel excavators for more than 30 years.
2: Are you a manufactuer or trading company?
A: We are a manufactuer.
3: What kind terms of payment can be accepted?
A: For terms of payment, We accept T/T.
4: What certificates are available in Machinery?
A: We currently have ISO9001, ISO14001, EAC certificates.
5: What about the delivery time?
A: Normally 7-15 days after receiving the deposit. In case of force majeure, time will be extended.
6: What about the Minimum Order Quantity?
A: MOQ is 1 pcs.
7: What is your port for export shipping?
A: Xiamen port
FAQ
What are your main products?
Are you a manufactuer or trading company?
What kind terms of payment can be accepted?
What certificates are available in Machinery?
What about the delivery time?
What about the Minimum Order Quantity?
What is your port for export shipping?
