XYB75SWXTJ 7ton Small Wheel Excavators Construction Equipment with Clamp Pipes

Economical type mechanical transmission wheel excavator. Operating Weight: 7ton Engine Model: XINCHAI 4D32 Rated Power: 48/2200 kw/rpm Bucket: 0.2m³

Product Description

Basic Info.

Model No. XYB75SWXTJ Drive Type Internal Combustion Drive
Bucket Capacity 0.2m³ Size Small-Sized
Certificates CE, ISO9001:2015, ISO14001:2015 Condition New
Machine Welght 6500KG Englne XINCHAI
Power/speed 48KW/2200rpm Max Digging Force 35kn
Max travel Speed 30km/h Transport Package Nude Packing
Specificatlon 6075mm*1950mm*2845mm Trademark Xinyuan
Origin China Production Capacity 10000 Pieces/Year

Product Description

XYB75SWXTJ is positioned at economical type mechanical transmission wheel excavator, is a new generation developed and manufactured by Xinyuan Heavy Industries after market research and analysis, combined with customers' needs, and improved and upgraded on the basis of B75W series products, implementing our brand's new design concept, with more excellent performance, appearance, comfort, durability and safety.

Powerful Engine

XINCHAI engine and direct-injection provides a stronger power for the excavator.

Unique Blowing Cooling System

XYB75SWXTJ uses the unique air blowing cooling system, which applies the principle of fluid dynamics and can discharge heat from the rear of the cockpit to keep the engine and hydraulic system in the best working condition at all times. High temperature airflow is directed to the rear of the fuselage for better driving comfort.

Compact Machine Size

XYB75SWXTJ is more compact in size and takes up less space when operating, and has an unparalleled advantage in loading operations because of its large operating range.

Large Chassis

XYB75SWXTJ chassis specifications are larger, the wheelbase is larger, and the wheel-end dual-tire configuration can provide strong support for the whole machine. Whether driving at high speed or steering, the stability is better. Equipped with unique engineering tires, the grip performance is stronger, more wear-resistant and resistant.

Comfortable Large Cab

The XYB75SWXTJ has a spacious interior structure with more space for the driver to move around effectively. The full-size glass design provides a wide field of vision and fewer blind spots.
The ergonomic layout of the operating device makes long time operation less fatiguing. Upgraded front intelligent instrument panel with full-color LCD screen has rich operation information display. Equipped with heating and cooling air conditioner, creating a more comfortable operating environment. There are electronic throttle knob, cigarette lighter, storage compartment, storage net pocket and other practical configurations, which are in line with the safety standards of hydraulic excavator operating room, equipped with fire extinguishers, escape hammer etc.


XYB75SWXTJ has higher safety. The side of the cab is equipped with large size glass, so the driver has a better side view. The whole vehicle is upgraded with light alarm system for safe driving.

Environmentally Friendly

Keep exhaust emission in line with our country's Emission Standards, the engine is environmentally friendly.

RANGE OF OPERATION Max Digging Reach 6560mm
Max Digging Depth 3370mm
Max Digging Height 6660mm
Max Dumping Height 4860mm
Min Front Radius 2325mm
Min Tail Radius 1860mm
DIMENSIONS Overall Length 6075mm
Overall Width 1950mm
Overall Height 2845mm
Wheel Base 2410mm
Tyre Type 825-16
Width of Grouding 430mm
track 1520mm
Min Ground Clearance 230mm
Width of Bulldozing 1910mm
Rising distance of Bulldozing 390mm
Height of Bulldozing 45mm
Width of Bucket 700mm
Engine XINCHAI 4D32
Rated Power 48KW
Rated Speed 2200rpm
Machine Weight 6500kg
Volume of Bucket 0.2m³
Set Pressure of Main Overflow Valve 24Mpa
Max Digging Force 35kn
Gradeability 35°
Max traction Force 40kn
Max travel Speed 30km/h
Swing Speed of Platform 11rpm
Fuel Tank Capacity 130L
Hydraulic Tank Capacity 130L


What are your main products?

Wheel excavators. We specialize in designing and manufacturing wheel excavators for more than 30 years.

Are you a manufactuer or trading company?

We are a manufactuer.

What kind terms of payment can be accepted?

For terms of payment, We accept T/T.

What certificates are available in Machinery?

We currently have CE, ISO9001, ISO14001, EAC certificates and more than 200 patents and certificates.

What about the delivery time?

Normally 7-15 days after receiving the deposit. In case of force majeure, time will be extended.

What about the Minimum Order Quantity?

MOQ is 1 pcs.

What is your port for export shipping?

Xiamen port
